Measurement Range | 0 – 100% |
Resolution | 1% |
Accuracy | 70% to 100% ±2 digits; 60% to 70% ±3% digits; below 60% unspecified |
Method | Dual wavelength |
Neonate Mode | Available |
Heart (Pulse) Range | 30 to 240bpm |
Resolution | 1bpm |
Accuracy | ±3bpm or ±3%, whichever is greater |
Display Type | Segment LED Display |
Display Parameters | SpO2, pulse rate, pulse bar |
Display Status Indication | Battery status indication, Memory full indication |
Display Date and Time | Yes |
Urgent Alarm | SpO2 value is higher/lower than predefined setting, sensor fall off, or pulse too high/low |
Reminding Alarm | Low battery |
Type of Sensors | Neonatal probe, Ear sensor, Forehead sensor, Reusable sensor, and Disposable sensor |
Operation Condition | 32°F to 113°F (0°C to 45°C); between 15% to 90% relative humidity, non-condensing |
Storage Condition | -4°F to 122°F (-20°C to 50°C); between 0% to 95% relative humidity, non-condensing |
Water-Resistance | Against water splash |
Impact-Resistance | Against repeat impact from 1 meter height |
Power Source | 4 x AA |
Battery Life | More than 100 hours |
Dimension (inch) | 5.51” x 2.76” x 1.26” |
Weight (lb) – Batteries Excluded | 0.53 |
