Specification |
||
System performance | Power source | Four 1.5V AA alkaline batteries |
Size of monitor w/o cuff | 160 (L) x 95 mm (W) x 66.5 mm (H), 400g with batteries. |
|
Cuff Size | 24-43 cm (9.4 - 16.9 inches) with air tube 100 cm |
|
Memory | Maximum 60 memory records | |
Power saving | Automatic power off if system idle for 3 minutes | |
System operating conditions | 10°C to 40°C (50°F to104°F), below 85% RH |
|
Meter storage conditions | -20°C to 60°C(-4°F to140°F), below 95% RH |
|
Power Supply Input | DC +6V / 1A (max) via Power Plug | |
Blood pressure measurement performance | Measurement unit | mmHg |
Systolic Measurement Range | 50 mmHg -255 mmHg | |
Diastolic Measurement Range | 25 mmHg -195 mmHg | |
Pulse Rate Measurement Range | 40 -199 beats / minute | |
Accuracy of Pressure | ±3 mmHg or ±2% of reading | |
Accuracy of Pulse rate | ±4% of reading |
Before Measurement |
|
1. Sit down for at least 10 minutes before measuring.
2. Place your elbow on a flat surface and relax your hand with the palm facing up. 3. Apply the proper pressure cuff and make sure the cuff is at the same height as your heart. |
|
Taking Measurements - Single Measurement |
|
1. Press to start. Then the cuff will begin to inflate automatically.
2. The "heart symbol will flash when a pulse is detected during the inflation. |
|
3. After the measurement, the monitor will display the systolic pressure, diastolic pressure and pulse rate. | |
Taking Measurements - Auscultatory Measurement (Only well trained persons may use this mode to measure blood pressure manually.) |
|
1. Press and hold until "AUS symbol" appears on the display with a beep. The cuff will begin to inflate and then deflate automatically.
2. Press to adjust the inflation pressure if necessary, and release to start the meter. |
|
3. The systolic pressure is measured when the operator first hears the sound of the pulse. Then the diastolic pressure is measured until the sound of the pulse is disappeared.
4. The monitor will return to 0 mmHg after the measurement is completed. |
